Quiet and smoothly
The brushed geared motors are well-suited for electric tricycle, as they provide consistent power delivery on flat terrain. They are also quieter than mid-drive motors.
Simpler and high-efficiency
The brushed geared motor omits a large number of transmission components, making the products structure simpler, and save energy in an efficient way to achieve a longer mileage.
Economic and durable
The brushed geared motors are low-cost compare to mid-drive motors. They retain all components inside the motor casing. and require little or even no maintenance.
Compact design and functional
The brushed geared motors are integrated into the electric wheelchair, either in the front or rear wheel. This design is simple and relatively straightforward.
| Items | Specifications | Notes |
| Rated power | 350丨450丨600 | W |
| Rated voltage | 24丨36丨48 | V |
| Non-load current | ≤2.5丨2.2丨2.0 | A |
| Non load speed | 3000丨3400丨3700 | RPM |
| Rated torque | 1.25丨1.45丨1.80 | N.m |
| Rated working current | ≤24丨16丨12 | A |
| Rated speed | 2700丨3000丨3200 | RPM |
| Efficiency | ≥78% | / |
| Reduction ratio | 1:5 | / |
| Insulation grade | F | / |
| IP level | IP44 | / |
