Quiet and smoothly
The brushless geared motors are well-suited for electric skateboard, as they provide consistent power delivery on flat terrain. They are also quieter than mid-drive motors.
Simpler and high-efficiency
The brushless geared motor omits a large number of transmission components, making the products structure simpler, and save energy in an efficient way to achieve a longer mileage.
Economic and durable
The brushless geared motors are low-cost compare to mid-drive motors. They retain all components inside the motor casing. and require little or even no maintenance.
Compact design and functional
The brushless geared motors are integrated into the electric skateboard, either in the front or rear wheel. This design is simple and relatively straightforward.
| Items | Specifications | Notes |
| Rated power | 60丨100 | W |
| Rated voltage | 24 | V |
| Non-load current | ≤1丨1.2 | A |
| No-load revolution | 1400丨1700 | RPM |
| Rated torque | 0.5 | N.m |
| Max torque | ≥1.8 | N.m |
| Rated revolution | 1200丨1500 | RPM |
| Rated working current | ≤4丨6 | A |
| Efficiency | ≥66丨72 | % |
| Working cycle | S2-60 | Min. |
| Insulation class | F | W |
| Out-shaft length | 22/37 | L/mm |
| Outer diameter | 70丨75 | D/mm |
| IP level | IP33 | / |
